Fiber Rackmounts, Cassettes & Accessories
RACKMOUNTS 2 RACKMOUNT FIBER DISTRIBUTION PANELS Indoor rackmount fiber distribution panels. All-purpose construction using powder coat steel. Panel sizes include 2, 3, 4, 6, 8, 12 adapter plate capacity options. Reversible rackmount ears for 19 or 23” installations. Optional 2, 3, 4RU flush mount 19” kit available. Slide out master tray is removable from either front or rear doors. PSC and MFM cassette ready for economical stocking and fast modular deployment, or available custom factory loaded with adapters, trays, pigtails and cable stubs. RACKMOUNT SLACK STORAGE UNITS Rackmount fiber slack storage enclosure to manage excessive lengths of preterminated cable assemblies in a small footprint. Designed to mount in a 19” or 23” relay rack. Removable sliding drawer with slack retention features. Available in 1RU and 2RU sizes. CUSTOM LOADING ORDERING INFORMATION RM XXX X XXX *X XX X CHASSIS COLOR FIBER PORTS FIBER TYPE ADAPTER PIGTAILS 1U2 - 1U 2 Plate 1U3 - 1U 3 Plate 2U4 - 2U 4 Plate 2U6 - 2U 6 Plate 3U8 - 3U 8 Plate 4UX - 4U 12 Plate B = Black W = White 006 012 024 036 048 072 096 144 R - Singlemode K - MM62.5 OM1 C - MM50 OM2 S - MM50 OM3 FC - FC FA - FC APC LC - LC SC - SC SA - SC APC ST - ST N - None 5 - 250um 9 - 900um R - 12 Fiber Ribbon ORDERING INFORMATION MODEL NO. DESCRIPTION DIMENSIONS (H XW XD) RM1U2B 1RU Patch Panel Empty 2 Adapter Plate Capacity 1.75” x 17.0” x 14.25” RM1U3B 1RU Patch Panel Empty 3 Adapter Plate Capacity 1.75” x 17.0”x 14.25” RM2U4B 2RU Patch Panel Empty 4 Adapter Plate Capacity 3.5” x 17.0” x 14.25” RM2U6B 2RU Patch Panel Empty 6 Adapter Plate Capacity 3.5” x 17.0” x 14.25” RM3U8B 3RU Patch Panel Empty 8 Adapter Plate Capacity 5.25” x 17.0” x 14.25” RM4UXB 4RU Patch Panel Empty 12 Adapter Plate Capacity 7.0” x 17.0” x 14.25” RM-FM-1U Flushmount Kit Rackmount 1U RM-FM-2/3U Flushmount Kit Rackmount 2U or 3RU RM-FM-4U Flushmount Kit Rackmount 4RU PSCxxxxxxx PSC Patch and Splice Cassette FST-ASF24 Splice Tray 24 Single Fusion FST-AMF06 Splice Tray 6 Mass Fusion (72 Fiber) ORDERING INFORMATION MODEL NO. DESCRIPTION RM1UBSS 1RU Slack Storage Enclosure RM2UBSS 2RU Slack Storage Enclosure DIMENSIONS RM1UBSS: 1.75”H x 17”Wx 14.25”D (4.45 cmx 43.18 cmx 36.20 cm) RM2UBSS: 3.5”H x 17”W x 14.25”D (8.89 cm x 43.18 cm x 36.20 cm) PSC CASSETTE COMPATIBLE (SEE PAGE 4) * To add PSC Cassettes, please see page 4 to complete model number
RACKMOUNTS 3 RM1U2S - SWINGOUT PATCH AND SPLICE PANEL The RM1U2S is a 1 RU, 2 termination panel rackmount fiber distribution unit designed to support both patching and splicing in one unit. The enclosure has a swing out master panel that allows for easy access of terminations, fiber management and splicing. CUSTOM LOADING ORDERING INFORMATION RM1U2S XXX X XX X FIBER PORTS FIBER TYPE ADAPTER PIGTAILS & SPLICE TRAYS 006 008 012 016 018 024 R = Singlemode K = MM62.5 OM1 C = MM50 OM2 S = MM50 OM3 LC - LC SC - SC SA - SC APC N = None 9 = 900um R = 12 Fiber Ribbon 5 = 250um DIMENSIONS Dimensions (height x width x depth): 1.75” x 17.0” x 13.26” (4.45 cm x 43.18 cm x 33.68 cm) ORDERING INFORMATION MODEL NO. DESCRIPTION MP1U3B 1RU Master Plate 3 LGX Module Capacity MP1U3BSS 1RU Master Plate 3 LGX Module Capacity with Slack Storage Support RACKMOUNT BRACKETS 1 RU 19 inch rackmount master plate with 3 LGX module/cassette capacity. Available with and without backbone cable slack storage support. Designed for LGX adapter plates, MTP cassette and Coupler splitter modules. STUBBED HOUSINGS Our wall and rackmount patch panels are also available factory loaded with a fiber stub pigtail. Contact your sales representative for additional information and product configuration assistance.
PATCH AND SPLICE CASSETTES 4 PSC SERIES - PATCH AND SPLICE CASSETTES Patch and splice cassette terminates up to 24 fibers in a single slot LGX-118mm industry standard patch panel. The modular design allows for simplified network expansion and upgrades. The PSC replaces the need for custom factory loading of patch and splice panels, or stocking multiple plates, splice trays and pigtails. Reduce lead time and increase flexibility with the PSC cassette solution. ORDERING INFORMATION SINGLE FUSION 900UM PIGTAILS INTERFACE PORTS OS-2 G.657A1 MM62.5 OM-1 MM50 OM-2/3/4 LC APC 6 PSC06RLA9B 12 PSC12RLA9B 24 PSC24RLA9B LC UPC 6 PSC06RLC9B PSC06KLC9B PSC06SLC9B 12 PSC12RLC9B PSC12KLC9B PSC12SLC9B 24 PSC24RLC9B PSC24KLC9B PSC24SLC9B SC APC 6 PSC06RSA9B 12 PSC12RSA9B SC UPC 6 PSC06RSC9B PSC06KSC9B PSC06SSC9B 12 PSC12RSC9B PSC12KSC9B PSC12SSC9B ST UPC 6 PSC06RST9B PSC06KST9B PSC06SST9B 12 PSC12RST9B PSC12KST9B PSC12SST9B MASS FUSION RIBBON PIGTAILS INTERFACE PORTS OS-2 G.657A1 MM62.5 OM-1 MM50 OM-2/3/4 LC APC 12 PSC12RLARB 24 PSC24RLARB LC UPC 12 PSC12RLCRB PSC12KLCRB PSC12SLCRB 24 PSC24RLCRB PSC24KLCRB PSC24SLCRB SC APC 12 PSC12RSARB SC UPC 12 PSC12RSCRB PSC12KSCRB PSC12SSCRB ACCESSORIES MODEL NO. DESCRIPTION LG1-CCH Conversion Plate LGX118 to CCH BKT-PSC1 Mounting Bracket, 1 Cassette BKT-PSC2 Mounting Bracket, 2 Cassettes PSC Series Cassette installed inside the 507F Series Enclosure using the BKT-PSC2 Mounting Bracket
ADAPTER PLATES 5 ORDERING INFORMATION STYLE ADAPTERS FIBER PORTS USE HOUSING SLEEVE MODEL # FC 6 6 SM/MM Metal Zirconia LG1-FC06SR-X FC 8 8 SM/MM Metal Zirconia LG1-FC08SR-X FC 12 12 SM/MM Metal Zirconia LG1-FC12SR-X FC APC 6 6 SM APC Metal Zirconia LG1-FA06SR-X FC APC 8 8 SM APC Metal Zirconia LG1-FA08SR-X FC APC 12 12 SM APC Metal Zirconia LG1-FA12SR-X LC Duplex 6 12 SM Blue Zirconia LG1-LC06D1-X LC Duplex 6 12 SM APC Green Zirconia LG1-LC06D3-X LC Duplex 6 12 MM Beige PB LG1-LC06DB-X LC Duplex 6 12 MM Aqua PB LG1-LC06DA-X LC Quad 6 24 SM Blue Zirconia LG1-LC06Q1-X LC Quad 6 24 SM APC Green Zirconia LG1-LC06Q3-X LC Quad 6 24 MM Beige PB LG1-LC06QB-X LC Quad 6 24 MM Aqua PB LG1-LC06QA-X SC 6 6 SM Blue Zirconia LG1-SC06S1-X SC 6 6 SM APC Green Zirconia LG1-SC06S3-X SC 6 6 MM Beige PB LG1-SC06SB-X SC 6 6 MM Aqua PB LG1-SC06SA-X SC 8 8 SM Blue Zirconia LG1-SC08S1-X SC 8 8 SM APC Green Zirconia LG1-SC08S3-X SC 8 8 MM Beige PB LG1-SC08SB-X SC 8 8 MM Aqua PB LG1-SC08SA-X SC Duplex 6 12 SM Blue Zirconia LG1-SC06D1-X SC Duplex 6 12 SM APC Green Zirconia LG1-SC06D3-X SC Duplex 6 12 MM Beige PB LG1-SC06DB-X SC Duplex 6 12 MM Aqua PB LG1-SC06DA-X ST 6 6 SM/MM Metal Zirconia LG1-ST06SR-X ST 6 6 MM Metal PB LG1-ST06SK-X ST 8 8 SM/MM Metal Zirconia LG1-ST08SR-X ST 8 8 MM Metal PB LG1-ST08SK-X ST 12 12 SM/MM Metal Zirconia LG1-ST12SR-X ST 12 12 MM Metal PB LG1-ST12SK-X NONE 0 0 N/A N/A N/A LG1-BLANK-X ADAPTER PLATES LGX compatible adapter plates available in black, white, and almond. Replace “-x” with plate color option: “-B “= black, “-W” = white, “-M” = almond/beige
TSL SERIES 6 TSL LGX PATCH & SPLICE ENCLOSURES The TSL LGX Fiber Termination Panels provide connectivity up to 144 (288 LC) ports. Available loaded with adapter plates, 250um, 900um or ribbon pigtails and splice bay. TSL shelves have been designed to meet Telcordia GR-63 and GR-449 requirements and are best utilized in Central Office and Data Center applications. 19” or 23” rackmount with modular LGX rack & stack form factor. CUSTOM LOADING ORDERING INFORMATION RM X UWL XXX X XX X CHASSIS FIBER PORTS FIBER TYPE ADAPTER PIGTAILS 4 = 4 RU Patch Only 5 = 5 RU Patch Only 7 = 4 RU Patch 3 RU Splice 8 = 5 RU Patch 3 RU Splice 9 = 5 RU Patch 4 RU Splice 072 096 144 R = Singlemode K = MM62.5 OM1 C = MM50 OM2 S = MM50 OM3 FC = FC FA = FC APC LC = LC LA = LC APC SC = SC SA = SC APC ST = ST N = None 5 = 250um 3m with Bay & Trays 9 = 900um 3m with Bay & Trays R = Ribbon 3m with Bay & Trays ORDERING INFORMATION ENCLOSURE RM4UWL RM5UWL RM7UWL RM8UWL RM9UWL PROPERTY 4RU PATCH 5RU PATCH 4RU PATCH 3RU SPLICE 5RU PATCH 3RU SPLICE 5RU PATCH 4RU SPLICE TYPICAL PORTS 72/96/144 144/288 72/96/144 144 288 PLATES 12 12 12 12 12 PLATE SIZE 118 170 118 170 170 SPLICE TRAYS 0 0 2 (3 LC) 3 6 DIMENSIONS 7 x 17 x 11 9 x 17 x 11 12.25 x 17 x 11 14 x 17 x 11 15.75 x 17 x 11 PACKAGING 10 x 20 x 14 12 x 20 x 14 15 x 20 x 14 18 x 20 x 14 18 x 20 x 14 WEIGHT 13 15 24 27 30 MATERIAL
MAMU SERIES 7 MULTI-ACCESS MODULAR UNIT (MAMU) The MAMU unit is comprised of several TSL termination shelves and one splice shelf. Each TSL is equipped with connector panels and fiber pigtails in either ribbon or 250um single fiber. Each splice shelf is equipped with mass-fusion or single-fusion splice organizers. All of the shelves are secured together in the factory, shipped and installed as a single unit. ORDERING INFORMATION FIBER PORTS CONNECTORS HEIGHT MODEL NUMBER DESCRIPTION OS-2 288 SC 15RU MAMU-5/5-288-RSC5 288 Port Singlemode SC 250um, (2) 144 Port 5RU Patch Panels, (1) 5RU Splice Bay, (6) 48 Fiber Splice Trays OS-2 288 SC-APC 15RU MAMU-5/5-288-RSA5 288 Port Singlemode SC-APC 250um, (2) 144 Port 5RU Patch Panels, (1) 5RU Splice Bay, (6) 48 Fiber Splice Trays OS-2 Ribbon 288 SC 13RU MAMU-5/3-288-RSCR 288 Port Singlemode SC Ribbon, (2) 144 Port 5RU Patch Panels, (1) 3RU Splice Bay, (2) 144 Fiber Mass Splice Trays OS-2 Ribbon 288 SC-APC 13RU MAMU-5/3-288-RSAR 288 Port Singlemode SC-APC Ribbon, (2) 144 Port 5RU Patch Panels, (1) 3RU Splice Bay, (2) 144 Fiber Mass Splice Trays OS-2 Ribbon 432 LC 15RU MAMU-4/3-432-RLCR 432 Port Singlemode LC Ribbon, (3) 144 Port 4RU Patch Panels, (1) 3RU SPLICE BAY, (3) 216 Fiber Mass Splice Trays OS-2 Ribbon 432 SC 18RU MAMU-5/3-432-RSCR 432 Port Singlemode SC-APC Ribbon, (3) 144 Port 5RU Patch Panels, (1) 3RU Splice Bay, (3) 216 Fiber Mass Splice Trays OS-2 Ribbon 432 SC-APC 18RU MAMU-5/3-432-RSAR 432 Port Singlemode SC-APC Ribbon, (3) 144 Port 5RU Patch Panels, (1) 3RU Splice Bay, (3) 216 Fiber Mass Splice Trays OS-2 Ribbon 864 LC 20RU MAMU-5/5-864-RLCR 864 Port Singlemode LC Ribbon, (3) 288 Port 5RU Patch Panels, (1) 5RU Splice Bay, (6) 216 Fiber Mass Splice Trays OS-2 Ribbon 864 SC 35RU MAMU-5/5-864-RSCR 864 Port Singlemode SC Ribbon, (6) 144 Port 5RU Patch Panels, (1) 5RU Splice Bay, (6) 216 Fiber Mass Splice Trays
RDC SERIES 8 RDC SERIES - RACKMOUNT DATA CENTER DISTRIBUTION PANELS Indoor high density rackmount fiber distribution panels. All-purpose construction using powder coat steel. Reversible rackmount ears for 19 or 23” installations. Stackable panels with top and bottom pass-through routing of high fiber count feeder cables or pigtails. PSC and MFM cassette ready for economical stocking and fast modular deployment, or available custom factory loaded with adapters, trays, pigtails and cable stubs. CUSTOM LOADING ORDERING INFORMATION RDC XXX X XX X X X FIBER PORTS FIBER TYPE ADAPTER PIGTAILS DENSITY SPLICE BAY 216 288 432 576 864 R - Singlemode K - MM62.5 OM1 C - MM50 OM2 S - MM50 OM3 T - MM50 OM4 LC - LC UPC LA - LC APC SC - SC UPC SA - SC APC 5 - 250um R - Ribbon S - Standard H - High B - Bottom M - Middle T - Top X - None ORDERING INFORMATION MODEL NO. DESCRIPTION RDC3 9RU Patch Panel 36 Adapter Plate Capacity - Empty RDCS6E 4RU Splice Bay 6 Tray Capacity - Empty TRAY18MF Splice Tray 18 Mass Fusion TRAY48SF Splice Tray 48 Single Fusion
